Name: HDPE Eflex HDPE /PE carbon corrugated pipe lastic Corrugated Tube
SKU: 0



Location： HOME > PRODUCTS > HDPE Pipe > HDPE drainage pipe > HDPE Eflex HDPE /PE carbon corrugated pipe lastic Corrugated Tube

HDPE drainage pipe

HDPE Eflex HDPE /PE carbon corrugated pipe lastic Corrugated Tube

HDPE carbon corrugated pipes have a wide range of uses in power engineering, mainly including cable protection (can effectively protect cables from external environment and increase the service life of cables), power drainage pipes (its inner wall is smooth and has low resistance, which can reduce the friction resistance of cables and improve the transmission efficiency of cables. In addition, good insulation performance prevents short circuits and leakage between cables, ensuring the safe operation of power equipment), grounding engineering (by burying HDPE carbon corrugated pipes underground and connecting them to grounding electrodes, it can effectively introduce static electricity and lightning generated by power equipment into the underground to ensure the safe operation of power equipment), cable trays (its good pressure resistance and corrosion resistance can effectively support cables and prevent cables from being affected by external pressure). In addition, HDPE carbon corrugated pipes have other uses in power engineering, such as being used as insulating materials for power equipment to isolate electrical connections between power equipment and prevent electrical accidents. In addition, it can also be used as a drainage pipe in power engineering to discharge rainwater, sewage and other wastewater to ensure the cleanliness of power engineering sites.

Ask questions

FREQUENTLY ASKED QUESTIONS



What are the common specifications of PVC pipe drainage pipes?

The conventional specifications of commonly used PVC pipe drainage pipes are as follows: nominal outer diameters are: 32mm, 40mm, 50mm, 75mm, 90mm, 110mm, 125mm, 160mm, 180, 200mm, 250mm, 315mm, 400mm, 500mm, 630mm, etc. PVC-U The length of the pipe is generally 4m or 6m, and customization is supported



How to solve the expansion and contraction problem of PVC drainage pipe?

The linear expansion coefficient of PVC drainage pipes is large, and expansion joints need to be installed during construction to solve the expansion and contraction problem. According to the calculation formula for the expansion and contraction of PVC-U drainage pipes caused by changes in ambient temperature:

△L=L·a·At

In the formula, △L-pipe expansion and contraction amount (m);

L-pipe length (mk)

a-Linear expansion coefficient, adopt 6×10-5～8X10-5-m/(m·℃);

△t-Temperature difference (℃)



What is the main use of PVC drain pipe?

Collect and remove wastewater, rainwater and sewage generated within the building. In urban infrastructure, drain pipes are used to collect drainage from roads, bridges, and other buildings. Drain pipes can also be used to vent gases, such as smoke exhaust ducts in kitchens and bathrooms.



What material is PVC drainage pipe made of?

PVC drainage pipe is a pipe material made of polyvinyl chloride resin as the main raw material. PVC pipes are easy to install, have a long service life and are simple to maintain, making them an ideal choice for modern building drainage systems.



What are the advantages of PVC drain pipes?

1. The surface hardness and tensile strength of the pipe are excellent, and the pipeline safety factor is high.

2. PVC drainage pipes have good aging resistance and their normal service life can reach more than 50 years.

3. The pipeline has excellent corrosion resistance to inorganic acids, alkali and salts, and is suitable for industrial sewage discharge and transportation.

4. PVC drainage pipes have a small friction coefficient, smooth water flow, are not easy to block, and require less maintenance work.

5. PVC drainage pipe material has a high oxygen index and is self-extinguishing.

6. The linear expansion coefficient of the pipeline is small, 0.07mm/℃, and the deformation affected by temperature is small. The thermal conductivity and elastic modulus are small, and compared with cast iron drainage pipes, they have excellent freezing resistance.

7. Bonding can be used to connect pipes and pipe fittings. The construction method is simple, the operation is convenient, and the installation efficiency is high.

BENEFITS & FEATURES

Quality product

Competitive pricing

Customized solutions

Fast delivery

General Service

Environmental friendly

SPECIFICATIONS

Material				PE polyethylene
Operating temperature				-40℃~+90℃
Color				Black,other color available upon request
Performance		Test conditions (state)	Test method		Test data	Data unit
Melt flow rate		230℃	ASTM D1238		2.0	g/10min
Density		--	ASTM D792		0.9	g/cm2
Tensile strength at yield point		--	ASTM D638		265	g/cm2
Elongation at yield point		--	ASTM D638		8	%
Flexural elasticity system		--	ASTM D790		13100	kg/cm2
Rockwell hardness		--	ASTM D785		81	R scale
Heat deformation temperature		--	ASTM D648		90	°C
Izod impact strength		--	ASTM D256		18/137	kg-cm/cm
Drop ball impact strength		--	LCY		22	ft-lb
Shrinkage		--	ASTM D955		14	%
Hose specifica tions	Inner diameter (mm)	Outer diameter (mm)	Wall thicknes s(mm)	Weight(k g/m)	Pitch(m m)	OD and Height( m)	Packagi ng unit (m)
AD42.0	30.0± 2.0	42.0± 1.0	0.95±0.2 5	0.28	10	0.90*0.5 0	200
AD67.0	50.0± 2.0	67.0± 1.0	1.25±0.3 5	0.45	16	1.40*0.5 5	200
AD105.0	80.0± 3.0	105.0± 3.0	1.35±0.4 5	0.82	26	1.60*0.6 0	100
AD128.0	100.0± 4.0	128.0± 3.0	1.70±0.8	1.20	33	1.80*0.8 0	100/200
AD185.0	150.0± 4.0	185.0± 5.0	2.10±0.9	2.4	50	2.2*1.2	50
AD280.0	200.0± 4.0	280.0± 5.0	2.15±0.8 5	4.0	66	2.4*1.4	40
Note: The above table refers to the following standards:GB/T13381.9
